IronRidge UFO Mid Clamp Clear
$3.00
Sale price
$3.00
Regular price
Skip to product information
IronRidge UFO Mid Clamp Clear
$3.00
Sale price
$3.00
Regular price
The IronRidge UFO Mid Clamp in Clear (mill) finish is the standard mid-row module clamp for IronRidge XR rail systems. The UFO design secures two adjacent panels with a single clamp — bonding both modules to the rail simultaneously for code-compliant grounding without additional hardware. It fits the most common residential module frame thicknesses (30–40mm).
Specifications
| Model | IronRidge UFO Mid Clamp |
| Finish | Clear anodized (mill) |
| Compatible Frame Thickness | 30–40mm module frames |
| Compatible Rail | XR10, XR100, XR1000 |
| Bonding | Integrated — bonds module frame to rail (no lug required) |
| Sold As | Individual clamps |
Key Features
- Bonds two panels to the rail in one operation — no separate grounding lug needed at each clamp
- Torque-set design — clamp stops over-tightening to protect module frames
- Compatible with all standard residential module frame sizes (30–40mm)
- IronRidge UFO system: pair with UFO End Clamps for row ends and corners
